| Weihua 10 ton electric hoist main product series |
| Product Series |
Types |
Lifting capacity (t) |
Lifting height (m) |
Lifting speed (m/min) |
| CD1/MD1 Low Headroom Wire Rope Electric Hoist |
Wire Rope Type |
1-16t |
6~30 |
3.5-8 |
| WH Electric Hoist |
Wire Rope Type |
1-32t |
9~48 |
3-6 |
| HB Explosion-Proof Wire Rope Electric Hoist |
Wire Rope Type (Explosion-proof) |
0.5-16t |
6~30 |
3.5-8 |
| NL Electric Chain Hoist |
Chain Type |
0.5-10t |
6~30 |
3-8 |
| YH Metallurgical Wire Rope Electric Hoist |
Wire Rope Type (Metallurgical) |
1-10t |
9~20 |
6.5-8 |
| 10-Ton General Purpose Electric Hoist |
Wire Rope/Chain Type |
10t |
6~30(Customizable) |
3 - 8 |
Buy 10 ton electric hoist type based on the usage environment:
1. General Environments: A standard 10 ton electric hoist can meet the lifting needs of most workshops, warehouses, and manufacturing plants.
2. Restricted Headroom: If your factory has a low ceiling, a low-headroom wire rope electric hoist is ideal, maximizing the effective lifting height.
3. Special Environments: If explosive gases are present, an HB-type explosion-proof hoist must be selected; if lifting molten metal in the metallurgical industry, a compliant YH Metallurgical Electric Hoist must be selected.
1. Specialized Industry Segmentation, Covering Harsh Working Conditions
Weihua has deeply developed and customized its 10 ton class products to meet the needs of different industries, rather than adopting a one-size-fits-all design.
Metallurgical Electric Hoist Specialty (YH Type): Designed for the high-risk scenarios of lifting molten metal in the metallurgical industry, the product features multiple safety measures including dual braking, dual limit switches, and heat insulation plate protection, strictly complying with relevant national safety regulations. The safety brake directly installed on its drum provides the highest level of protection for lifting safety.
Low Headroom Electric Hoist Design (WH Type): For newly built factories or spaces with limited space, the low headroom series effectively increases the lifting stroke height and can even reduce the building height, thereby helping customers save on construction costs.
2. Wide range of applications
The Weihua 10 ton electric hoist can be flexibly applied to:
Bridge cranes: Installed on single-girder or double-girder bridge cranes, suitable for indoor locations such as factories, assembly workshops, steel mills, and warehouses.
Gantry cranes: Installed on gantry cranes, suitable for outdoor locations such as shipyards, construction sites, railway freight yards, and logistics terminals.
Fixed installation: Can be directly installed on a fixed lower suspension rail for independent use.
3. Strong Customization Capabilities
Weihua's 10 ton electric hoist offers a wide range of customization options:
Lifting Height: Standard 6m, 9m, 12m, 18m, customizable up to 30m and above
Control Methods: Drop control, wireless remote control, cab control
Speed Options: Single-speed or dual-speed lifting to meet different precision requirements
Didn't find your industry solution? Consult our technical experts immediately.
