Shipbuilding gantry cranes (commonly referred to as gantry cranes) are typically employed in shipbuilding, wind power, and offshore engineering industries. Primarily used for product hoisting, assembly, and final assembly operations, they offer multiple functions including lifting, transporting, and segmental aerial rotation. Their role in segmental rotation and hull assembly is particularly crucial in shipbuilding operations. The crane primarily consists of a portal structure, upper trolley, lower trolley, main travel mechanism, electrical control system, maintenance crane, boarding elevator, power supply cable reel, wind protection device, and alignment correction device. The shipbuilding industry predominantly employs upper and lower traversing trolleys. In wind power and offshore engineering, both upper/lower traversing and parallel trolley configurations are utilized, depending on operational requirements. Design, manufacturing, and inspection comply with international and domestic standards including FEM, DIN, IEC, AWS, and GB.

Common product capacities include 200 t, 300 t, 400 t, 500 t, 600 t, 800 t, 1000 t, 1200 t, 1500 t, 2000 t, 2500 t, 3000 t, and 3600 t. Weihua Shipbuilding Gantry Cranes incorporate multiple leading technologies, utilizing variable frequency intelligent control systems to collect real-time operational data, monitor equipment status, and ensure maintenance safety. With superior overall performance, they represent a professional, efficient, and secure equipment solution. The world's first 3600t shipbuilding gantry crane achieved a new breakthrough in lifting capacity.


1. Floating Crane Installation of Xinhantong 500t Gantry Crane

Project Scope: Weihua Marine Engineering employed floating crane technology for the first time to install a 500t-153m gantry crane at Xinhantong Shipbuilding Heavy Industry Co., Ltd. The main girder weighed 2,100 tons, with the entire crane weighing 6,000 tons.

Technical Breakthrough: Through coordinated operations of 1000t and 2500t floating cranes, the project completed rigid/flexible leg rotation, main girder unloading, and upper/lower trolley installation within 4 days, demonstrating high-efficiency adaptability in challenging environments.

Functional Features: Dual-girder design with upper trolley capacity of 2×175 tons and lower trolley capacity of 250 tons. Capable of segmental aerial rotation and large-span lifting, meeting requirements for large ship section assembly.

2. New Chinese-Style Intelligent Crane at Wuhu Shipyard's Weihai Base

‌Project Background: Weihua delivered dozens of New Chinese-Style cranes to Wuhu Shipbuilding's Weihai “Super Factory,” supporting the launch of the global shipbuilding industry's first “lights-out workshop.”

‌Technical Advantages: Crane height reduced by 30%, weight decreased by 25%, energy consumption cut by 20%, and equipped with anti-sway technology (sway angle ≤0.2°), enhancing intelligence and safety.

Application Results: Achieved 80% workshop automation, reduced labor by 40%, and enabled efficient human-machine collaborative production.

3. Wuhu Shipyard 450t Shipbuilding Gantry Crane Installation

‌Project Highlights:‌ The 450t gantry crane designed by Weihua for Wuhu Shipyard spans 92 meters with a rated lifting capacity of 450 tons, supporting ship hull turning and joining operations.

‌Intelligent Design:‌ Utilizes ANSYS simulation analysis, variable frequency control systems, and safety monitoring systems to achieve high-precision positioning and safe switching across multiple operating conditions.

4. ‌Hailong Wind Power 3000t Gantry Crane‌

‌Industry Position‌: China's first 3000-ton gantry crane with a total lifting capacity of 3000 tons and a 120-meter span, used for offshore wind power equipment hoisting.

‌Technological Innovation: Single-girder dual-trolley system with four-drum dual-hook synchronous structure. Combined with hydraulic synchronous lifting technology, installation completed in 14 days—setting industry efficiency benchmarks.

5. ‌Haili Wind Power 3600t Gantry Crane‌

Global Breakthrough: The world's first 3600-ton gantry crane with a lifting height of 128 meters and a total lifting capacity of 3600 tons, capable of supporting 1800-ton component aerial rotation.

Smart Manufacturing Upgrade: Utilizing 3D digital mockup design and 5G full-process tracking, the production cycle was reduced from 8 months to 5 months, embodying the “smart manufacturing” transformation.
